Function Description Notes:
F0 Headlight Directional
F1 Bell Choose Bell sound via CV164
F2 Horn Choose Horn sound via CV163
F3 Coupler Clank
F4 Dynamic Brakes Models without D/B go to idle
when F4 is on while moving
F5 DPU Lights Toggles head/ditch lights off in
the leading direction and on at
reduced brightness on trailing
end.
F6 Ditch Lights (Directional) OFF if F12 active
F7
F8 Startup Number Boards, Walkway and
Ground lights come on.
F9 Drive Hold OFF if F10 active.
F10 Independent Brakes
F11 Radiator Fan
F12 Headlight Dimmer Turns off F6 while active.
F13 Air Dryer
F14 Numberboards OFF Toggles NB OFF after F8 is ON
F15 Isolation Switch Disconnects motor drive if active.
F16
F17 Auto Brake Set/Release
F18 Sanding Valve
F19 Short Air Let Off
F20 Air Compressor
F21 Hand Brake
F22 Cab Door
F23 Engine Hood Door
F24 Reverser Center Locks out throttle controls when
ON
F25 Cooling Shutters
F26 Manual Notch - UP
F27 Manual Notch - DOWN
F28 Manual Notching Logic Toggle ON - OFF to use feature
F29 Load Simulation Primary Load
F30 Automatic Brake
F31 Fade Out Sound
Information for function mapping, sound slots and more can
be found in ESU technical manual #51989 for the Loksound
V5 DCC decoder. The document is available for download at
www.LokSound.com.
FUNCTION CHART
