Handle
Pull out the handle to open the door.
Mounting of the soapstones
Place the soapstone sides at the sides of the stove.
Push the enclosed bolt through the soapstone sides
from the outside and fasten.
SCAN Andersen 10
You should read this manual as well as the General Instructions for Installation before beginning the installation.
Regulation for combustion air. Push the button sideways. Left
position is closed and right position is open. The air is used for the
combustion and regulates the output of the stove.
Combustion air % Primary air % Max. fuel, kg Fuel consumption, kg/h
75 75 1,96 1,7
Adjustment of the air + fuel consumption (EN 13240):
