Note : anvil size and puller size shall be the same
INSTRUKCJA OBSŁUGI
UNINSTALLATION OF PULLER
1.SCREW OFF ANVIL AND LOCKNUT 2.PULL OUT THE PULLER
4.SCREW ON LOCKNUT THEN ANVIL3.INSERT THE PULLER FROM THE TOOL
FORWARD
DESIGNED IN FRANCE BY
E-410NV
min.
M4
maks.
M10
Wrong WrongCorrect
