PRODUCT IMAGE / BUTTON DESCRIPTION / DISPLAY
blinksilluminated o󰀨
1
Display
2
Menu button set
conrms menu settings
3
Menu button minus
menu settings
4
Menu button plus
menu settings
5
LED channel 1 -5
6
Open button
roller shutter moves up or
stops
7
stop button
the roller shutter will stop
8
Close button
roller shutter moves up or
stops
9
channel selection but-
ton
to select a specic channel
Description LEDs
Time switch - functionHand-held transmitter - function
