14 english
Maintenance
• Overhauls, maintenance work, cleaning, as well as the
elimination of any malfunctions must only be undertak-
en after turning off the motor.
• All protective and safety equipment must be reinstalled
immediately upon completion of any repair or mainte-
nance work.
• Clean and lightly oil the spindle thread of the tool holder
when changing tools.
• When possible, the tail stock sleeve should be removed
by unscrewing it, cleaned and then sprayed with a dry
lubricant. Grease the threaded spindle.
• Check the eccentric clamp of the tailstock as well as the
tool holder and adjust if necessary. In addition, tighten
the hex nut under the bracket.
• Check the drive belt and replace when necessary.
Accessories
Article Art. No.
Turning lathe extension 4902301701
Additional tools 5er set 88002716
Additional tools 6er set 88002717
Screw chuck 7400 7200
Socket chuck Ø 30 mm 7400 8600
Socket chuck Ø 40 mm 7400 7300
Socket chuck Ø 60 mm 7400 8700
Driver plate Ø 80 mm 7400 8800
Three-jaw chuck Ø 100 mm 7400 8900
Four-jaw chuck Ø 125 mm 7400 7400
Drill chuck 3 – 16 mm cone mandrel MK-2 7400 7700
You can nd other accessories in our current catalogue or
at www.scheppach.com.
Trouble shooting
Problem Possible Cause Help
Motor doesn’t start
a) No electricity
b) Defective switch, condenser
c) Defective extension cord
a) Check fuse
b) Have an electrician inspect unit
c) Unplug cord, inspect and replace, if
necessary
Work piece atters while
working
a) Working piece becomes loose
while working
b) Work piece is not properly centered
c) Rotational speed is too high
a) Follow the instructions in the operating
manual
b) Follow the instructions in the operating
manual
c) Select a lower rotational speed
Tool rest or tailstock
cannot be clamped
Setting the eccentric clamping Return the hexagonal nut at the bottom side
about ½ rotation with the socket spanner
