8 The Low Quality Source lights when
clock regeneration must loosen its
algorithm due to poor source. AKA the
“buy better gear” light. You should pretty
much never see this light. If you do, check
your source and cables.
9 This lights when muted. Press button 3
to unmute. It also ashes when Yggdrasil
is rst turned on and it’s doing self-checks.
10 This is the remote control sensor. Don’t
block it if you want the remote to work.
1
3
7
8
9
The remote allows you to cycle
through inputs, mute the output,
and invert the output.
Changing the Battery
1. Push the remote open by inserting the
end of an open paper clip into the hole in
the back and pressing rmly.
3. Replace the battery inside with one of
the same type.
4. Reassemble the remote by rst inserting
the clear LED in the front, then drop-
ping the panel down onto the matching
magnets.
REMOTE
1
2
3
1
2
3
Yggdrasil+ is upgradable via its modular
design—the USB Input, SPDIF Input, DSP,
and DAC/Analog cards are all updatable.
When it’s time for your upgrade, we’ve taken great care
to ensure that Yggdrasil+ won’t have to come back to us.
However, if you want the condence of a factory-installed
upgrade, the Schiit Upgrade Queueing system ensures
you can keep your DAC until the moment we’re ready to
do the upgrade.
If you’d like to be the rst to know about upgrades as they
become available, sign up on the SPAM link on our site.
