4
GB
Installation of the safety washer
1
2
4
3
5
490
560
Min. 30/Max.50
CABINET DIMENSIONS
Min 5mm
Min 20mm
Min 20mm
Min 5mm
SAFETY DISTANCES WITH FURNITURE
30mm
30mm
60
