Schrack MC3-XAV - Breaker Removal and Subsequent Fitting; Removing the Breaker; Subsequent Fitting (-XR)

3/4
04/05 AWA1230-2094
Herausnehmen des Schalters
Disconnect the breaker
Démontage du disjoncteur
Estrazione dell’interruttore
Desconexión del interruptor
Вынимание выключателя
MC4
MC3
-XR
Nachrüsten
Subsequent fitting
Equipement ultérieur
Instalación posterior
Montaggio successivo
Дооснащение
1
2
2
1
1
1
74 72 3.13 3.23D1/C1 4.11/4.13 1.11/1.13 1.21/1.23 1.31/1.334.21/4.23
7170 75 3.14 3.24D2/C2 4.12/4.14 1.12/1.14 1.22/1.24 1.32/1.344.22/4.24
1(2) x 0.50 – 2.5 mm
2
1(2) x 0.75 – 2.5 mm
2
a = 6 – 7
Z2
1 Nm
a
-XR...
