2 Command Summary Date Code 20010625
SEL-311L Instruction Manual
HIS n Show brief summary of the n latest event reports.
HIS C Clear the brief summary and corresponding event reports.
IRI Force synchronization attempt of internal relay clock to IRIG-B time-code input.
MET k Display instantaneous metering data (currents and alpha plane) for local and remote terminals. Enter k
for repeat count.
MET B k Display instantaneous metering data for local terminal including voltage. Enter k for repeat count.
MET D Display demand and peak demand data. Enter MET RD or MET RP to reset.
MET E Display energy metering data. Enter MET RE to reset.
MET M Display maximum/minimum metering data. Enter MET RM to reset.
QUI Quit. Returns to Access Level 0. Terminates SEL Distributed Port Switch Protocol (LMD) protocol
connection. Available in all access levels.
SER n Show the latest n rows in the Sequential Events Recorder (SER) event report.
SER m n Show rows m through n in the Sequential Events Recorder (SER) event report.
SER d1 Show rows in the Sequential Events Recorder (SER) event report from date d1.
SER d1 d2 Show rows in the Sequential Events Recorder (SER) event report from date d1 to d2. Entry of dates is
dependent on the Date Format setting DATE_F (= MDY or YMD).
SER C Clears the Sequential Events Recorder (SER).
SHO n Show relay settings (overcurrent, reclosing, timers, etc.) for Group n.
SHO L n Show SEL
OGIC
®
control equation settings for Group n.
SHO G Show global settings.
SHO P n Show Port n settings.
SHO R Show Sequential Events Recorder (SER) settings.
SHO T Show text label settings.
STA Show relay self-test status.
SUM Show newest event summary.
SUM A Acknowledge oldest even summary.
SUM N View oldest unacknowledged event report.
SUM N [A] Display or acknowledge event summary number “N”.
TAR R Reset the front-panel tripping targets.
TAR n k Display Relay Word row. If n = 0 through 45, display row n. If n is an element name (e.g., 50G1)
display the row containing element n. Enter k for repeat count.
TIM Show or set time (24 hour time). Show time presently in the relay by entering just TIM. Example time
22:47:36 is entered with command TIM 22:47:36.
TRI Trigger an event report.
Access
Level B
Commands
Access Level B commands primarily allow the user to operate output contacts. All Access Level 1
commands can also be executed from Access Level B. The screen prompt is: ==>
BRE n Enter BRE W to preload breaker wear. Enter BRE R to reset breaker monitor data.
CLO Close the circuit breaker. See the Note in the Set Close discussion, following Figure 6.1 for more
information concerning the CLO command.
GRO n Change active group to Group n.
OPE Open the circuit breaker. See the Note following Figure 5.2 and the Note in the Lockout State
discussion, following Table 6.1 for more information concerning the OPE command.
PUL n k Pulse output contact n (OUT101–OUT107, ALARM, OUT201–OUT212) for k (1–30) seconds.
Parameter n must be specified; k defaults to 1 if not specified.
