14. Press the ENT pushbutton.
The front panel displays the following:
STATUS
Relay Status
15. Press the ENT pushbutton.
The front panel displays the following:
Serial Num
000000000000000000000000
16. Press the ENT pushbutton.
The front panel displays the following:
Confirm Hardware
Config (Enter)
17. Press the ENT pushbutton.
The front panel displays the following:
Accept New Config?
No Yes
18. Select Yes and press the ENT pushbutton.
The front panel displays the following:
Config Accepted.
Enter to Reboot
19. Press ENT.
The relay restarts and the ENABLED light is turned on to indicate the card was installed correctly.
After reconfiguration, the relay updates the part number, except for the digits shown below. These digits
remain unchanged, i.e., these digits retain the same character as before the reconfiguration. A
communications card (DeviceNet or EIA-232/EIA-485) installed in Slot C will be reflected as an empty
slot in the part number. A regular 4 DI/4 DO card and a hybrid 4 DI/4 DO card have the same device ID.
When interchanging these two cards, the part number for the respective slots should be updated manually.
Use the STATUS command to view the part number.
Use the PARTNO command from the Access Level 2 to enter the exact part number of the relay.
20. Update the side-panel drawing with the drawing sticker provided in the option card kit. If necessary,
replace the rear panel with the one applicable for the card and attach the terminal marking label provided
with the card to the rear-panel cover.
21. Reconnect all connection plugs, and add any additional wiring/connectors required by the new card.
PART NUM = 751001B5X1X7086020X
