Page 22
Zeropoint Current Angle Quick Check (Echelon2 Sensor Type Only)
Software V1.7 adds a new feature that allows users to quickly check the current angle of the Zero-
point Calibration from the main Ride menu. This enables riders to quickly check to verify the sensor
is still calibrated without having to navigate through the service menu.
To do the quick check:
1. Place the calibration tool on the ywheel.
2. Turn the brake knob clockwise until the brake stops.
3. From the main Ride menu, hold the LIGHT button for 3 seconds.
The console will display the Zeropoint angle for 10 seconds, after the 10 seconds the console will
return to the main Ride menu.
