Page 27
Changing the batteries
To change the batteries in the Echelon2 console, you will need the following tools:
• 2.5 mm hex (allen) wrench
• Philips screwdriver
To change the batteries, do the following:
1. Remove the two hex head screws that hold the connector
protective cap in place and remove the cap.
2. Unplug the connector.
3. Remove the Philips screw holding the console to the
bracket.
4. Slide the console o the bracket to access the batteries.
