Thank you for purchasing Scorpion Sky Strider 280
FPV racing frame.
Please, prepare the following tools and materials before
assembly.
3mm phillips 1.5mm hex 2mm hex Thread locker
Parts
UPPER FRAME ＊2 ALUMINIUM CROSS MEMBER ＊2
LOWER DECK ＊1 UPPER DECK＊1
FRONT FRAME MOUNT ＊1 TRANSMITTER BOARD ＊1
FIXING PLATE BRACKET ＊4 LENS FIXING BOARD ＊1
LENS UPPER BOARD ＊1 LENS LOWER BOARD ＊1
DECK CROSS MEMBER ＊6 SIDE STRAIGHTENER ＊4
FRONT/REAR STRAIGHTENER ＊2 UNDERCARRIAGE＊4
MOTOR ARM ＊4 LANDING GEAR *4 SUSPENSION BALL ＊4
UPPER ANGLED ARM CLAMP ＊4 MOTOR GUARD ＊4
LOWER ANGLED ARM CLAMP ＊4 ANTENNA TUBE ＊2
Screws
M3 *4 set screw x4
M2 * 4 round Phillips’ x 8
M2.5 *6 hexagonal round
head x26
M2.5 *6 hexagon head x2
M2.5 *12 hexagon head x4
M2.5 *14 hexagon head x8
M3 *6 flat head x2
x4
