HoW to reload tHe alpride system
ALPRIDE SYSTEM | SCOTT 2014 | 3
1
2
4
do Not...
Push the airbag towards the left and Push the uPPer
Part towards the right. left has to overlay the right Part
Push the airbag towards the bottom and
Push the lower Part towards the toP.
5
7
6
8
1
2
close the ziPPer
close the ziPPer
Push the airbag on the right side
towards the toP
... Roll the aiRbag... fold the aiRbag
