SCOTT ASPECT 760 User Manual

ENGLISH
03 |
GENERAL MANUAL | OWNER’S MANUAL 2021
1 Saddle
2 Seat post
3 Seat post clamp
4 Pannier rack
5 Rear light
6 Brake rear
7 Rotor
8 Front derailleur
9 Cassette sprockets
10 Rear derailleur
11 Kickstand
12 Chain
13 Chainring
14 Crank
15 Pedal
16 Stem
17 Bell
18 Handlebars
19 Brake lever
20 Shifter
21 Brake lever/shifter
22 Headset
23 Front lamp
24 Brake front
25 Rotor
26 Fork
27 Hub dynamo
Wheel:
28 Quick-release/
thru axle
29 Spoke
30 Rim
31 Reflector ring
32 Tyre
33 Hub
Frame:
1
Top tube
2
Down tube
3
Seat tube
4
Chainstay
5
Seat stay
6
Head tube
7
Rear shock
Suspension fork:
I
Fork crown
II
Stanchion tube
III
Lower leg
IV
Drop-out
16
18
19
20
22
24
25
28
29
30
32
33
1
2
3
6
7
9
10
12
13
14
II
III
I
1
2
3
4
5
6
7
IV
c

SCOTT ASPECT 760 Specifications

General

Frame	Aspect 6 Alloy 6061
Fork	Suntour XCE28 100mm travel
Shifters	Shimano SL-M315 R-fire plus / 2 way release w/gear indicator
Crankset	Shimano FC-TY501, 42x34x24
Brakes	Tektro HD-M275 Hydr. Disc
Rotor	160mm rotor
Handlebar	Syncros 3.0, 720mm, black
Seatpost	Syncros 3.0, 31.6mm
Seat	Syncros 3.0
Headset	A-Headset, 1 1/8"
Hub (Front)	Formula DC-19FQR
Spokes	14 G, stainless, black
Rims	Syncros X-20, 32H
Front Tire	Kenda Booster, 29x2.4"
Rear Tire	Kenda Booster, 29x2.4"
Approx weights in KG	14.5 kg
