05 |
ENGLISH
ROAD BIKE | OWNER’S MANUAL 2021
1 Saddle
 2 Seat post
3 Seat post clamp
4 Brake rear
5 Rotor
6 Front derailleur
7 Cassette sprockets
8 Rear derailleur
9 Chain
10 Chainring
11 Crank
12 Pedal
13 Stem
14 Handlebar
15 Armrests
16 Extensions
17 Bull-horn handlebars
18 Brake lever
19 Shifter
20 Brake lever/shifter
21 Headset
22 Brake front
23 Rotor
24 Fork
Wheel:
25
Quick-release/
thru axle
26 Spoke
27 Rim
28 Tyre
29 Hub
Frame:
1
Top tube
2
Down tube
3
Seat tube
4
Chainstay
5
Rear stay
6
Head tube
SCOTT CYCLO-CROSS BIKE
13
14
20
21
24
22
23
25
26
27
28
29
1
2
3
6
4
5
7
8
9
10
11
2
3
4
5
6
1
