8.2 Power on/off
Press and hold the Power button for at least 1 second to turn the LCD display on/off.
8.3 Pedal Assist System (PAS)
Press the up or down button to increase or decrease the PAS (pedal assist mode) level. By
default, level 5 is the maximum selectable level and provides the maximum possible help from
the motor of the pedal-assist bicycle, whereas level 1 provides the minimum help from the
motor. Level 0 does not provide help from the motor.
The display is preconfigured to offer 5 levels of assistance, during reconfiguration (see para-
graph 9.11) you can opt for the range 0-3, 0-5 and 0-9. These options do not change the maxi-
mum assistance provided but are only a varying distribution of assistance levels. The table
below is attached for a comparison between the different range modes.
8.4 Speed – Avg Speed – Max Speed
Press the left button to switch between the speed – avg speed – max speed function
The speed function shows the real-time speed during the use of the bicycle, the avg speed
function shows the average speed maintained during the last use of the bicycle, the max speed
function shows the maximum speed maintained during the last use of the bicycle.
8.5 Trip – Odo – Time
Press the right button to switch between the trip – odo – time function
The trip function consists in showing the partial km travelled on your electric bike, the odo
function consists in showing the total km travelled on your electric bike, the time function shows
the accumulated time of use after the last use of your bike.
3 level 5 level 9 level
0 0 0
1 2 3
3 5 9
2 6
3 5
4 7
8
4
1 1
2
No power assist
17
