SCREENLINE SL2190 - Safety Instructions; Important note; 2 wires connection with bipolar push-botton switch; 3 wires connection with IR remote control

Our products are certied
Pellini S.p.A. - 26845 Codogno (LO) ITALY • via Fusari, 19
T. +39 0377 466411 • F. +39 0377 436001 437635
info@pellini.net • www.pellini.net
The company is certied by
ISO 9001: 2008 Certication No. 2351/2
pellinindustrie
®
2 wires connection with bipolar push-botton switch 3 wires connection with IR remote control
Cable section: 0.35 mm
2
Cable length: 2 metri
- unless they receive caretaking or instruction
on the use of the equipment from a person
in charge of their safety. Children must be
looked after in order to prevent them from
playing with the equipment. DO NOT allow
children to play with the xed control devices.
Keep the portable (remote) control devices
out of children’s reach.
Check the equipment on a frequent basis, so
as to make sure that no unbalancing or wea-
ring evidence or damage to wires and springs
can be detected. DO NOT use the equipment
when repairs or adjustment are necessary.
The features of the guided part must be com-
patible with the rated torque and the rated
working time; clearly state how to connect
the driving motor to the guided part and how
to adjust the control devices.
If the power wires are damaged, they must
be replaced by the manufacturer or by its
service team, or by a person with equivalent
qualication.
WARNING! Important safety instructions. For
people’s safety, it is essential that the infor-
mation here below be followed. Keep this
instruction manual.
This equipment is not designed to be used by
persons (including children) whose physical,
sensorial or mental skills are limited, or who
lack the necessary experience or knowledge
Pellini S.p.A.
ScreenLine External motor mod. SL2190
MAX Torque: 300gr/cm
24V/3.6V dc 0.5A/3.4A; 12W
Continuous operation
IP40; 0°C÷+70°C
III
Important note
The motor body should be left in its box and
not taken out till it is to be tted to its support.
Avoid contact between motor bodies, as the
sudden mutual attraction could cause dama-
ge to the magnets. When handling the mo-
tor body, keep it at safe distance from metal
objects that could be strongly attracted by the
magnet, as this could also cause damage to
the latter. Furthermore, please note that the
magnet may attract small metal bodies that
may come between the glass and the magnet,
this causing the motor fail to operate.
Safety instructions
