Operation & Maintenance Manual──LG946L Wheel Loader
48
from front. Luxury vehicular decoration, air condition and warm wind outside, operation
space is larger and comfortable.
8 TECHNICAL PERFORMANCE & PARAMETER
8.1 Performance of whole machine
Standard lift arm Long lift arm
Bucket capacity
2.3 m
3
2.3 m
3
Rated loading capacity
4000N 3600N
Lifting time (full load) ≤5.7s ≤5.7 s
Lowering time (empty bucket) ≤3.6 s ≤3.6 s
Dumping time (empty bucket) ≤1.0 s ≤1.0 s
Travel speed
Forward:
1
st
0～13 km/h 0～13km/h
2
nd
0～38 km/h 0～38km/h
Reverse gear
1
st
0～17km/h 0～17km/h
Max. breakout force ≥125 kN ≥125 kN
Max. traction force (supplied by engine) ≥120 kN ≥120 kN
Tipping load ≥80 kN ≥72 kN
Max. climbing angle 28° 28°
Min. turning radius(outside of rear wheel) 5365 mm 5365 mm
Level passing radius (outside of bucket) 6117 mm 6286 mm
Max. turning angle
38° 38°
Tire charge pressure:
Front wheel
0.34±0.01 MPa 0.34±0.01 MPa
Rear wheel 0.285±0.01 MPa 0.285±0.01 MPa
8.2 Principle Dimension and Weight
Length (bucket on ground) 7295mm 7600 mm
Width (outside of wheels) 2574 mm 2574 mm
Bucket width 2766 mm 2766 mm
Height 3240 mm 3240 mm
