Section 07 ELECTRICAL SYSTEM
Sub-Section 03 (CHARGING SYSTEM)
07-03-9
SPX, GSX AND GTX MODELS
1. Negative battery cable on top of small ground wire
5. Apply dielectric grease on battery posts.
6. Verify cable routing and attachment.
SP and GTS Models
Secure RED positive battery cable using right
strap of battery.
1. Strap retaining RED positive cable
2. Vent tube connected and secured in support
F01H63A
1
F01H0AA
2
1
