152
Add coolant, see
Recommended
Engine Coolant
for specification, to
adjust coolant level between
marks as required. Use a funnel to
avoid spillage. Do not overfill.
3. Properly tighten the expansion
tank cap. Reinstall seats.
NNOOTTEE::
A cooling system that frequently re-
quires coolant is an indication of leaks
or engine problems. See an author-
ized Sea-Doo dealer.
RReeppllaacciinngg tthhee EEnnggiinnee CCoooollaanntt
Coolant replacement should be per-
formed by an authorized Sea-Doo
dealer, a repair shop or person of your
own choosing.
IIggnniittiioonn CCooiillss
AAcccceessssiinngg tthhee IIggnniittiioonn CCooiill
1. Remove tether cord from the en-
gine cut-off switch.
2. Remove the engine access
panels.
TTYYPPIICCAALL
3. Remove the engine cover.
RReemmoovviinngg tthhee IIggnniittiioonn CCooiill
1. Disconnect ignition coil connector.
NNOOTTIICCEE
DDoo nnoott pprryy oonn iiggnniittiioonn ccooiill uussiinngg
aannyy ttooooll..
2. Remove ignition coil retaining
screw.
3. Remove ignition coil from spark
plug by rotating coil side to side as
you pull up.
IInnssttaalllliinngg tthhee IIggnniittiioonn CCooiill
1. Install ignition coil on spark plug.
2. Align the retaining screw hole of
the ignition coil with the threaded
hole on the valve cover.
3. Push the ignition coil all the way
down until it rests on the valve
cover.
4. Install and tighten retaining screw.
TTiigghhtteenniinngg TToorrqquuee
Ignition coil
retaining
screw
9 ± 1 Nm
(80 ± 9 lbf-in)
5. Reconnect ignition coil connector.
SSppaarrkk PPlluuggss
RReemmoovviinngg tthhee SSppaarrkk PPlluugg
1. Remove the ignition coils. Refer to
Removing the Ignition Coil
.
2. Clean the spark plug and cylinder
head with compressed air.
MAINTENANCE PROCEDURES
