23) Rear Seat Storage
Compartment
The rear seat storage compartment is
a convenient location for water-skis,
paddles, anchor and rope, etc.
24) Rear Storage
Compartment
REAR STORAGE COMPARTMENT
1. Engine cover opened
Convenient rear storage location to be
used to carry large personal articles.
Ideal location for spare Personal Flota-
tion Device (PFD), towels, lunch etc.
To open engine cover, unsnap the
straps then lift it.
The gas assist cylinders will ease
opening and hold engine cover open.
25) Jet Pump Water Intake
The water is drawn up by the impeller
through this opening. It minimizes en-
try of foreign objects into the propul-
sion system.
Refer to M
2
Jet Drive Operator‘s Guide
for more detailed information.
26) Bow and Stern Eyelets
Bow Eyelet
Eyelets can be used for mooring, tow-
ing and as a tie-down point during
transportation.
TYPICAL
1. Bow eyelet
Stern Eyelets
This eyelet allows a rope with a hook,
a closes end or an open end to be at-
tached.
WARNING
Never leave any heavy or break-
able objects in the storage com-
partment. Never operate the craft
with the storage compartment cov-
er open.
WARNING
Never leave any heavy or break-
able objects in the storage com-
partment. Never operate the craft
with the engine cover open.
F10L2SY
1
WARNING
Keep away from intake grate while
engine is on. Items such as long
hair, loose clothing or personal flo-
tation device straps can become
entangled in moving parts result-
ing in severe injury or drowning.
F09L3YY
1
