STEP 10: Push the two base cabinet/top cabinet
combinations together. Insert a M6x16mm screw
through the two interior end cover holes and fasten
with a M6 flange nut.
STEP 11: Push a stackable cabinet combination towards either side of
the base cabinet/top cabinet combination. Insert a M6x16mm screw
through the two interior end cover holes and secure with a M6 flange nut.
APMSHFP series | Issue 1 21/10/19
Original Language Version
© Jack Sealey Limited
M6x16mm
screw x2
M6x16mm
screw x2
M6
flange
nut
