GSS150815 Issue: 1 - 24/08/12

© Jack Sealey Limited

Original Language Version

Ø4 x 10mm Rivet

Ø3 x 10mm Rivet

Pad Shoot bolt

Part No (74)

Keeper Part No (71)

Pad Shoot bolt plate

Part No (75)

60mm Barrel shoot bolt

Part No (70)

Mid height wall bracket

Part No (72)

Base bracket
