MONACO ASSIST
TM
TECHNICAL SPECIFICATION
A
B
C
G
H
D
Basic dimensions
A Overall height 1205mm/47.5in
B Back height 860mm/34in
C Seat to floor height 380-500mm/15-20in
D Inside back width 505mm/20in
E Chair length 870mm/34in
F Reclined length 1090mm/43in
ii
iii
iv
Arm height options*
I Low 180mm/7in
J High 210mm/8in
Seat depth options
K Min 350-480mm/14-19in
L Max 490-550mm/19-22in
Leg rest length
M 420mm/16.5in
Recline and tilt angles
ii Back angle recline
100° - 120°
25° range
iii Leg rest angle
75° - 107°
32° range
iv Angle adjustable seat
-10 ° - +20°
30° range
K
M
L
E
F
Available seat and overall widths
G (Seat width) H (Overall width)
380mm/15in 635mm/25in*
450mm/18in 690mm/27in*
500mm/20in 690mm/27in*
550mm/22in 740mm/29in*
600mm/24in 790mm/31in*
Chair weight unloaded is 57 Kg/125.6 lb/10.56 Stone.
Chair user weight limit is 159 Kg/364 lb/25 Stone.
I J
* Dimension excludes legrest belt. Add 35mm/1.5in if
belt is used.
*Please note when adapting cushion thickness arm height
will be aected. Contact technical@seatingmatters.com
for further information.
