SEBSON IR_OUT_E - Settings and Testing; Sensitivity Adjustment; Time Setting (Switch-off Delay); Function Test

11
Sensitivity when switching (with regard to the ambient brightness):
This setting control can be used to regulate the switch-on sensitivity of this unit
depending on the ambient brightness (between 3 and 2.000 LUX).
Time setting (switching off delay):
The duration of the operating time can be set continuously from approx. 10s to
15min. The timer is restarted if a movement from the sensor is detected before the
set time has elapsed.
Function test:
Ensure that the motion detector is not obscured. Ensure that the coverage area is not restricted by items such as
through large furniture. To set the detection range and the daylight test, turn the knobs to the positions shown. The
motion detector is activated after a warm-up phase of approx. 30s. If no further movement takes place in the
sensing area of the sensor, the sensor switches off.
Technical Data:
Operating voltage:
220 -240V AC 50/60Hz
Maximum power consumption:
Max. 1.200W
Max. 600W
Consumption in standby:
< 0,5W
Electrical protection:
IP65
Protection class:
II
Detection moving speed:
0,6-1,5m/s
Ambient temperature:
-20° - +40°C
Humidity:
<93%
