Secure SNDI-813V User Manual

Datascrip technical manuals
©2011 – 2012 by SECURE. All rights reserved.
2
SNDI-813V
Key Features
 Up to 1.3 megapixel (1280 × 960) resolution
 Standard video compression with high compression ratio
 Progressive scan CMOS, capture motion video without incised margin
 Support dual stream, and the sub-stream for mobile surveillance
 High-performance and long service life Infrared LED, Approx. 10 to 30 meters IR range
 IR cut filter with auto switch
 Two-way audio
 PoE (Power over Ethernet)
 Ingress Protection level: IP66
 Auto-iris, electronic shutter for different surveillance environments
 Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10
 Other functions: heartbeat, alarm, reset button, mirror, etc.
Specification
Model
Parameter
SNDI-813V
1.3 Megapixel CMOS ICR Infrared Network Bullet Camera
Camera
Image Sensor 1/3" Progressive Scan CMOS
Min. Illumination
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
0.028 Lux @ (F2.0, AGC ON) ,0 Lux with IR

Secure SNDI-813V Specifications

General

Brand	Secure
Model	SNDI-813V
Category	Security Camera
Language	English
