Communications harness is
routed under MRCTYB PCB and
white plastic from location
circled on MRCTYB to location
circled on main PCB.
Minimum 1/4” separation from Reverse Polarity or
Master Box (MRCTYB) wiring to all power limited
wiring. Area to right of bold line is NOT power limited.
MRCTYB
