Secutron MR-2100

MR-2100/MR-2200 Installation Manual
23
See next page for battery selection calculations.
Notes:
* Each relay, when active, will draw 17mA. The alarm current will depend on how many relays
are programmed to activate on alarm.
** Represents three (3) devices in alarm. For each additional device, add 5mA.
*** Alarm current depends on module configuration. Please refer to MRCTYB installation
Instructions for further detail.
**** If MR-2644 and MR-D1010R are powered from AUX:
MR-D1010R - 20mA Stby, 115mA Alarm (max)
MR-2644 - 30mA Stby, 70mA Alarm (max)
Add above currents for each annunciator or fiber optic modem, (i.e.) if 2 are present then multiply
above by 2.
Device Standby Total Alarm Total
Device Type Qty. Current Standby Current Alarm
MR-2200 mainboard w/ LCD
1
x 110mA 110mA 175mA 175mA
display & primary power supply
M22NTWN Network Card x 50mA _____ mA 50mA 50mA
Optional Internal
Components
MRNC2 NAC output extender x 10mA _____ mA 65mA _____ mA
MRRL4 function relay o/p extender
x 5mA _____ mA 17mA* _____ mA
MRLD8 8-zone LED annunciator
x 5mA _____ mA 15mA** _____ mA
MRDL dual line DACT
x 40mA 40mA 65mA 65mA
MRCTYB polarity reversal / municipal tie
x 20mA 20mA _____ mA*** _____ mA***
Addressable
Inputs
Smoke detectors x _____ µA _____ µA _____ µA _____ µA
Smoke detectors
x _____ µA _____ µA _____ µA _____ µA
Thermal detectors
x _____ µA _____ µA _____ µA _____ µA
Monitor modules
x _____ µA _____ µA _____ µA _____ µA
Control modules
x _____µA _____ µA _____ µA _____ µA
Fault isolator modules
x _____ µA _____ µA _____ µA _____ µA
See Appendix C for details on compatible addressable devices and their respective current draw.
Audible Notification Appliances (mA) x
Visual Notification Appliances (mA) x
AUX Power Load****
TOTAL (A): TOTAL (B):
