Sega Let's Go Jungle User Manual

ASSEMBLY AND INSTALLATION
19
6
4
Coilanyexcessharnessandsecuretoeithercabinetusingthecablerouterstted..
5
Fit the DLP and Main Cabinet together.
Takecarenottotrapyourhands,ngers,orany
of the wires.
6
Attach the DLP joint sides to the connecting
sections on the left and right sides of the cabi-
net. Fix each in place with four hexagon bolts
andfouratheadscrews.Theboltshaveat
and spring washers attached. Use the hexagon
boltsontheDLPsideandtheatheadscrews
on the Main Cabinet side. The two DLP joint
sides are identical and each can be used on
either side.
FIG. 6-1e
FIG. 6-1fDLP JOINT SIDE
HEXAGON BOLT (4), black
DLP JOINT SIDE
FLAT HEAD SCREW
(4 ea.)
M6x16, w/at & spring washers
M6x16
