88
CONTROL UNIT
11
8
Remove the hexagon nuts attaching the volume bracket upper to the volume and remove it from the bracket.
The bracket will be used with the replacement part.
9
The wire attached to the volume will be used with the replacement part. Remove the old heat shrink tubing
attached to the wire using the nippers or cutters.
10
Use the soldering iron to melt the solder and remove the wire from the old volume. You must take the ut-
most care when using the soldering iron.
11
If the lead wire on the end of the wire terminal is less than ve millimeters use wire strippers or cutters to
peal back the covering.
12
Pass the wire through each of the heat shrink tubes.
13
Solder the wire terminal to the replacement volume.
Use the wiring diagram to make sure you don’t solder in the wrong place.
14
Use the industrial dryer to apply heat and attach the heat shrink tubing to the soldered area.
15
Attach the gears and bracket to the volume.
16
Connect the connector.
17
As in the above adjustment method, with the Control Unit level, engage the gears with the D cut face of the
volume axis in the direction shown in the diagram and attach it to the Control Unit. (See FIG. 11-3e).
18
Fix the bracket in place with the two screws.
19
Reattach the Gun Cover and the muzzle.
20
Reattach the Control Unit to the cabinet.
21
Turn on the power and use the calibration screen to alter the volume values.
