Topper Mounting Instructions [continued]
7. Insert the HDMI cord into HDMI slot 1.
8. Chase the HDMI cable and the monitor power cord
through the chase hole on back of the topper mount.
HDMI Port 1
Wire Chase Hole for
Power and HDMI cable.
HDMI Port 1
Connection of DVI to HDMI adapter, HDMI
splitter, and HDMI Cables to the PC.
C
D
E
F
A
B
HDMI Port location on both Topper
and Door Monitor
To Next Page
