How to use the compass (Only for models with the
compass bezel (ring))
•
Please use the compass in places where the sun is visible or its location is known.
* The compass is so designed to provide only a rough indication of directions, and should not be used where accuracy is critical.
■ Using the 24-hour hand
•
Before using the compass, it is necessary to set the 24-hour hand to the current time of your area.
•
If daylight saving time (summer time) is in effect in your area, be sure to set your watch one hour behind the
current time before using the rotating compass.
●
In the Northern Hemisphere
* In low latitude areas (south of the Tropic of Cancer), the compass
may not function properly at certain times of the year.
1
Set “N (North)” on the rotating compass
bezel (ring) to the 12 o’clock marker.
* “N” may be another mark.
* In the case of a ring, it may have a crown, etc. for
operation.
2
While keeping the dial level, point the
24-hour hand in the direction of the
sun.
The direction marks on the rotating compass indicate
the corresponding directions.
24-hour hand
12 o’clock marker
Sun
EastWest
South
North
EN
25
1
HOW TO USE
●
In the Southern Hemisphere
* In low latitude areas (north of the Tropic of Capricorn), the
compass may not function properly at certain times of the
year.
1
Set “S (South)” on the rotating
compass bezel (ring) to the 24-hour
hand.
* In the case of a ring, it may have a crown, etc. for
operation.
2
While keeping the dial level, point the
12 o’clock marker in the direction of
the sun.
The direction marks on the rotating compass
indicate the corresponding directions.
24-hour hand
12 o’clock marker
Sun
East
West
South
North
EN
26
1
HOW TO USE
■ Using the hour hand
•
Before using the compass, it is necessary to set the hour hand to the current time of your area.
•
If daylight saving time (summer time) is in effect in your area, be sure to set your watch one hour behind the
current time before using the rotating compass.
●
In the Northern Hemisphere
* In low latitude areas (south of the Tropic of Cancer), the
compass may not function properly at certain times of the
year.
1
While keeping the dial level, point the
hour hand in the direction of the sun.
2
Set “S (South)” on the rotating
compass bezel (ring) to the middle
point of the arc between the 12 o’clock
marker and the time scale indicated
by the hour hand.
The direction marks on the rotating compass
indicate the corresponding directions.
* In the case of a ring, it may have a crown, etc. for
operation.
Hour hand
12 o’clock marker
Sun
East
West
South
North
EN
27
1
HOW TO USE
●
In the Southern Hemisphere
* In low latitude areas (north of the Tropic of Capricorn), the
compass may not function properly at certain times of the
year.
1
While keeping the dial level, point the
12 o’clock marker in the direction of
the sun.
2
Set “N (North)” on the rotating
compass bezel (ring) to the middle
point of the arc between the 12 o’clock
marker and the time scale indicated
by the hour hand.
The direction marks on the rotating compass
indicate the corresponding directions.
* “N” may be another mark.
* In the case of a ring, it may have a crown, etc. for
operation.
Hour hand
12 o’clock marker
Sun
East
West
South
North
EN
28
1
HOW TO USE
