Reassembling
1)Install the BALANCE COMPLETE WITH STUD to the MAIN PLATE.
2) Set the BALANCE COCK WITH REGURATOR and tighten the BALANCE COCK SCREW.
3) Temporarily set the stud to the STUD SUPPORT.
Do not engage the balance-spring to the REGULATOR PIN. The balance-spring passes outside of the
REGULATOR-PIN at this stage.
4) Push back the stud parallel to the slit of the STUD SUPPORT.
5) Engage the balance-spring with the slit of the REGULATOR PIN.
* When assembling the BALANCE COMPLETE, pay great attention
not to deform the balance-spring, especially at the second
bend.
