[ CALENDAR MECHANISM 2 ]
15
Hour wheel
0271/0273 *** 9
0962 025
10 Guard for day-date corrector
16 Minute wheel and pinion setting transmission wheel
261 *** screw 0012 ***
17 Intermediate date driving
wheel and pinion Guard for day-date corrector
0817 300 setting transmission wheel
0836 ***
Date indicator driving wheel
0802 ***
12
0962 ***
Cannon pinion
0962 023
Date corrector setting wheel
0737 ***
Dial holding spacer
4408 172
0014 577
0011 220
0014 295
4/18
PARTS LIST
Cal. 4R35B / 4R36A
Intermediate wheel for date setting
E
Lower shock
absorbing
27-1
Intermediate wheel
for date setting B
Intermediate wheel
for date setting C
0225 414
13
20
27-1
19
18
Lower shock
absorbing cap jewel
27-1
Lower hole jewel frame
for shock-absorber
Types of oil
AO-3 (Moebius A)
SEIKO Watch Oil S-6
SEIKO Watch Oil S-4
*1
*1
*2
*2
*3
*3
11
14
