TECHNICAL GUIDE
Cal. 5D88A
18/51
id
Winding stem
iff
Clutch wheel
igg
Winding pinion
Wh
en installing the WINDING STEM, support the WI
NDING PINION and the CLUTCH WHEEL by
using the movement holder as illustrated below.
Winding stem
Winding pinion
if
ig
id
Clutch wheel
ul
Yoke
Se
curely hook the arm of the YOKE inside the pin of the main plate, taking care so as not to
deform the arm of the YOKE.
uk
Setting lever
uj
Setting lever jumper
uh
Setting lever jumper screw
Se
curely engage the pin on the backside of the SETTING LEVER (indicated by
in the illustration
below) with the guiding slit of the SW
ITCHING LEVER. Sliding the SWITCHING LEVER towards the
“a” portion in the illustration below will make this easier.
