Page #5 background imageLoading...
Page #5 background image
5
No
1 1
SELFSAT-H21D+
SELFSAT-H30D+
Antenna
Body
2
A1
B1 1
Angle
Bracket
3B2 1
Main
Support
4B3 1
Window
Bracket A
5B4 1
Window
Bracket B
Fix
Bracket A
Fix
Bracket B
6B5 1
7B6 1
Symbol Part name Image Quantity
8B7 1
Spanner
Box Content
