Specifications
521456 03/07 Printed in Germany Sennheiser is a registered trademark of Sennheiser electronic GmbH & Co. KG. www.sennheiser.com
Polar diagram Frequency response curve
Variants Cat. No. EAN UPC
e 815 S-C with microphone clip 009425 40 06087 09425 9 6 15104 09425 3
e 815 S-J with cable, 5 m, jack plug and microphone clip 009426 40 06087 09426 6 6 15104 09426 0
e 815 S-X with cable, 5m, XLR-plug and microphone clip 009427 40 06087 09427 3 6 15104 09427 7
Microphone e 815 S
Pick-up pattern cardioid
Frequency response 80 – 12,000 Hz
Nominal impedance 350 O
Min. terminating impedance 1000 O
Sensitivity in free field, no load (1 kHz) 1,5 mV/Pa
Weight 330 g
Dimensions 48 x 180 mm
