Frequency Response
Polar Pattern
Frequency response 40Hz…18kHz
Transducer principle Pressure gradient
receiver
Pick-up pattern Cardioid
Front-to-back-rejection at 1kHz at 180˚ >25dB
Sensitivity (free field,no load) 1kHz
1.8mV/Pa ≡ −55dB (0dB=1V/Pa)
≡ −75dB (0dB=1V/µbar)(USA)
Nominal impedance at 1kHz 350Ω
Min.terminating impedance 1kΩ
Sensitivity to magnetic
field at 50Hz ≤1µV/µT
Weight 60g
Dimensions ∅ 33 x 59mm
Delivered with pouch and drum clip
