Frequency Response
Polar Pattern
Frequency response 40Hz…18kHz
Transducer principle Pressure gradient
receiver
Pick-up pattern Super-cardioid
Front-to-back-rejection at 1kHz at 120˚ >15dB
Sensitivity (free field,no load) 1kHz
1.5mV/Pa ≡ −56.5dB (0dB=1V/Pa)
≡ −76.5dB (0dB=1V/µbar)(USA)
Nominal impedance at 1kHz 350Ω
Min.terminating impedance 1kΩ
Sensitivity to magnetic
field at 50Hz ≤1µV/µT
Weight 180g
Dimensions 55 x 34 x 134mm
Delivered with pouch and mic clip
