Sensus RadioRead 510 User Manual

6
Single and Dual Port – Wired Installation
1. Open Model 510 Radio door.
2. Secure Model 510 Radio to a wall utilizing the screw holes above the battery
compartment.
3. Run the register wires through the bottom of the Model 510 Radio and connect to
the appropriate terminals.
4. Once all registers are connected, activate unit (see activation section).

Sensus RadioRead 510 Specifications

General

Brand	Sensus
Model	RadioRead 510
Category	Transceiver
Language	English
