MANUAL DEL USUARIO • FORZA 150
13
Left handlebar control system
Clutch grip (1): To start the engine or make a gear shifting, press the grip to release the drive system and cut off the clutch.
Dimmer switch (2): When dimmer switch is turned up to ”
” (high beam) position, the head light is in high beam and the high beam
indicator lamp on the instrument panel is lit. On contrary, when it is turned down to “
”(low beam) position, the low beam is lit.
Turning signal operation When the switch is turned to left “←
” position, the left turning signal lamp is lit and the indicator lamp on instrument
panel flashes. When the switch is turned to right “←
” position, the right turning signal lamp is lit and the indicator lamp on instrument
panel flashes.
Warning: Whenever you are going to change lane or make a turning, timely turn ON the turning signal lamp. After lane change or turning, timely
turn the signal light OFF.
Horn button (3): Press “
” button and the horn will sound
