Opening the cover
∙ First press the button to
ventilate the unit. Then push down on
both front corners of the cover to release
it.
∙ Lift up the cover and remove the bag.
Hint: Should any residual liquid be found
inside the sealed seam, wipe the seam
dry and let it go through another sealing
cycle. Caution: The bag opening must
be absolutely dry, to guarantee a seal
that is safe and airtight.
∙ To interrupt the process, press the
button.
∙ Disconnect the appliance from the
mains.
Using with a vacuum container
(Vacuum container not included)
Hint: Suitable vacuum containers
can be ordered conveniently on the
internet from our homepage http://www.
severin.de under the section „Service /
Ersatzteil-Shop“.
Preparing the container
∙ Place the prepared food in a vacuum
container.
∙ Replace the lid on the container.
∙ Caution: The rim of the container
(seals, gaskets etc.) must be absolutely
clean, dry and free of fat or oil!
Preparing the air-extraction process
∙ Connect the appliance to the mains.
∙ Push down on both front corners of the
cover to release it.
∙ Lift up the cover.
∙ Slide the larger opening of the
connecting hose rmly onto the suction
outlet.
∙ Fit the other end of the hose to the valve
on the vacuum container.
Air extraction:
∙ Press the
button.
∙ The LED is lit while the air is
being extracted from the container.
∙ Once the process is complete, the LED
goes out and the hose can be removed.
∙ To interrupt the process, press the
button.
∙ Disconnect the appliance from the
mains.
Opening the container
∙ To open the vacuum container, push
down on the valve using a suitable
implement. Once air is admitted, the lid
can be taken off.

SEVERIN FS 3601 Specifications

General

Quantity	1
Number of vacuum bags	5
Control type	Buttons
Product color	Black
Maximum working width	300 mm

Weight and Dimensions

Depth	85 mm
Width	408 mm
Height	57 mm
Weight	1000 g
