Seville Classics WEB493 - Page 2

Parts List
Please make sure you have all the parts on this list.
If you’re missing parts, contact us for replacements at
(800) 323-5565 or send an email to Support@SevilleClassics.com
Assembly Instrucons
STEP 1. Aach Casters
TIP: Make sure channels on each
SIDE FRAME (A) face each other.
Push the SLEEVES (F) into the
boom poles of SIDE FRAMES (A)
unl ush with boom.
Push CASTERS (G) and LOCKING
CASTERS (H) into the SLEEVES (F)
unl click is felt.
STEP 2. Aach Crossbars
Fit a WASHER (J) between SIDE
FRAME (A) and CROSSBAR (B).
Flat side of washer MUST sit in end
crossbar. Curved side of washer
MUST t against side frame.
Screw BOLT (I) through outer holes
on SIDE FRAME (A) and into
CROSSBAR (B).
TIP: Do not ghten unl drawers
are fully inserted.
STEP 3. Assemble Drawers
Aach DRAWER PULL KNOBS (K) to
all DRAWERS (D, E) with SCREWS
(J) and screwdriver.
A. Side frame (2)
B. Crossbar (4)
C. Shelf (1)
D. Shallow drawer (6)
E. Deep drawer (2)
F. Sleeves (4)
G. Caster (2)
H. Locking caster (2)
I. Bolt (8)
J. Washer (8)
K. Screw (8)
L. Drawer Pull Knob (8)
M. Allen Wrench
