Page #267 background image
8
Service
Fault table CiA402 profile
Operating Instructions – MOVIMOT
®
flexible
267
8.7.6 Fault 8 Speed monitoring
Subfault: 8.1
Description: Speed monitoring – motor mode
Response: Output stage inhibit
Cause Measure
Speed controller operates at setting limit (mecha-
nical overload or phase failure in supply system
or motor).
Increase the delay time set for speed monitoring,
or reduce the load.
Encoder not connected correctly. Check the encoder connection and direction of
rotation. If necessary, increase the current limiting
or reduce the acceleration values.
Encoder has incorrect direction of rotation. – Check encoder connection and direction of ro-
tation. If necessary, increase current limiting or
reduce acceleration values.
– Check motor lead and motor, check line
phases.
Subfault: 8.2
Description: Speed monitoring – generator mode
Response: Output stage inhibit
Cause Measure
Speed controller operates at setting limit (mecha-
nical overload or phase failure in supply system
or motor).
Increase the delay time set for speed monitoring,
or reduce the regenerative load.
Encoder not connected correctly. Check the encoder connection and direction of
rotation. If necessary, increase the current limiting
or reduce the deceleration values.
Encoder has incorrect direction of rotation. – Check the encoder connection and direction of
rotation. If necessary, increase the current limiting
or reduce the deceleration values.
– Check motor cable and motor. Check the line
phases.
Subfault: 8.3
Description: Maximum speed at motor shaft
Response: Output stage inhibit
Cause Measure
Actual speed exceeded "Maximum speed at mo-
tor shaft" limit value (index 8360.9 / 8361.9). This
limit value is set at startup matching the motor
and gear unit.
Reduce the maximum speed.
29128668/EN – 12/2019
