8
Service
Fault table CiA402 profile
Operating Instructions – MOVIMOT
®
flexible
268
8.7.7 Fault 9 Control mode
Subfault: 9.1
Description: Magnetization of motor not possible
Response: Output stage inhibit
Cause Measure
User-defined current limit or output stage monito-
ring reduced possible maximum current to such a
degree that required magnetizing current cannot
be set.
– Reduce the output stage utilization, e.g. by re-
ducing the PWM frequency or reducing the load.
– Increase the user-defined current limit.
Subfault: 9.2
Description: Requested operating mode not possible with active control mode
Response: Output stage inhibit
Cause Measure
The current FCB activated an operating mode.
The active control mode does not support this op-
erating mode, for example "position control" or
"torque control" with U/f control mode.
Start up control mode that supports the required
operating mode. Connect an encoder if neces-
sary. Select an operating mode that is supported
by the current control mode.
Subfault: 9.3
Description: Absolute rotor position not available
Response: Output stage inhibit
Cause Measure
The current control mode requires an absolute ro-
tor position. The encoder selected for "Source of
actual speed" does not provide an absolute rotor
position.
Use an absolute encoder, or identify the rotor po-
sition using FCB 18.
Subfault: 9.4
Description: Correct current supply of motor not possible
Response: Output stage inhibit
Cause Measure
Failed to set required current during premagnetiz-
ation.
Check the cabling, or disable the function "Cur-
rent monitoring during premagnetization".
Subfault: 9.5
Description: Maximum output frequency exceeded
Response: Output stage inhibit
Cause Measure
Maximum output frequency exceeded. Reduce the maximum speed.
29128668/EN – 12/2019
