Appendix A
Antenna Installation: One-turn triangular loop mounted 12 feet horizon-
tally above ground. Used SG-2020 transceiver.
Notes:
Lowest Usable
Frequency =
2.6 MHz
Fwd = 20.2w
Ref = .2w
SWR = 1.02:1
Bottom of band
f (MHz)
Middle of band
f (MHz)
Top of band
f (MHz)
Fwd Ref Fwd Ref Fwd Ref
80 3.510 MHz
20w .7w
3.750 MHz
20w .7w
3.990 MHz
20w 0
40 7.010 MHz
21w .2w
7.150 MHz
21w .1w
7.290 MHz
21w 1.3w
30 10.110 MHz
21w 0
10.125 MHz
21w 0
10.140 MHz
21w 0
20 14.010 MHz
23w 0
14.175 MHz
22w .2w
14.340 MHz
20w 2.1w
17 18.078 MHz
21w 0
18.118 MHz
21w 0
18.158 MHz
21w 0
15 21.010 MHz
21w 0
21.225 MHz
20w 0
21.440 MHz
20w 1w
12 24.900 MHz
20w .1w
24.940 MHz
20w .1
24.980 MHz
20w .1
10 28.010 MHz
19w .6
28.850 MHz
19w 1.2
29.690 MHz
21w 0
VSWR 1.1:1 1.1:1 1:1
VSWR 1:1 1:1 1.1:1
VSWR 1:1 1:1 1:1
VSWR 1:1 1:1 1.2:1
VSWR 1:1 1:1 1:1
VSWR 1:1 1:1 1.1:1
VSWR 1:1 1:1 1:1
VSWR 1.1:1 1.1:1 1:1
