A
B D
C
GOGGLES AND MASK
ASSEMBLY
1. Present the side part of goggles in front
of hook.
2. Engage the crowbar on the part side until
it comes in continuity with the edge of the
mask.
3. Make the sameoperation on the otherside.
DISMANTLING
To unsettle the whole helmet, you just have
to take off the plastic part xed to elastic
bandages, the side part of goggles (g. C).
DISMANTLING
Goggles is easily knockdown of the mask thanks
to their system of xation, a simple drive will be
enough for you (g D).
10
