ASSEMBLY ASSEMBLY
Tool Storage
Posts
Upper Cord
Hook
Lower Cord Hook
POWER CORD
For cord access, rotate upper hook
down and remove cord.
Use cord holder on the side of wand
to hold cord in place while vacuuming.
UPPER CORD HOOK CORD HOLDER
1. Place Pod down onto Nozzle.
2. Insert Wand into Pod.
3. Insert Handle into wand.
4. Attach Hose to back of pod.
5. Remove Odor Neutralizer Technology Dial from bag. Flip up the dial handle,
align the teal arrows, then insert the dial into the nozzle.
6. To lock and engage the dial, rotate it counterclockwise until it clicks into the desired
odor intensity setting.
* More detailed Odor Neutralizer Technology assembly instructions and visuals on the
following two pages.
IMPORTANT: For proper operation, ensure all connections are securely clicked into place.
(Click)
2
(Click)
1
(Click)
3
(Click)
4
(Turn to
Click)
6
5
