Sharp 25VT-K100 - Cabinet and Mechanical Parts; Cabinet Assembly Components

25VT-K100
25VT-CK10
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
66
CABINET AND MECHANICAL PARTS
1 CCABA1304MES0 M Cabinet Compete Ass’y BL
1-1 CBTN-0228WEV0 M Control Button Ass’y AG
1-2 - Not Available - – Cabinet-Front —
1-3 GCOVA0052PESA R Cover, R/C. AC
1-4 HBDGB1008MESA M Badge, SHARP AA
1-5 HDECQ0079PESA R LED Decoration AD
1-6 HDECQ0081PESC M Cassette Flap-Door AG
1-7 JBTN-0160PESA R Button, Power AD
1-8 JBTN-0225PESA R Button, Eject AD
1-9 JBTN-0261PESA M Button, Control AE
1-10 XTASD30P12000 J Screw AA
1-11 MSPRC0003MEFW M Button Spring AA
1-12 MSPRD0123AJFJ J Cassette Flap-Door AC
Spring
1-13 TCAUH3045MEZZ M Caution Label AA
(25VT-K100)
1-13 TCAUS3011MEZZ M Attention Label AA
(25VT-CK10)
1-14 TCAUS3004MEZZ M Warning Label AA
(25VT-CK10)
2 LHLDW1007MEKZ M Degaussing Coil Holder AD
3 MSPRT0002MEZZ M Spring, Grounding Strap AA
4 PMAGF3001MEZZ M Purity Magnet AG
5 PSPAG0012MEZZ M Wedge (Gum), AA
Yoke Positioning x3
6 QEARC2508MEZZ M Wire, Grounding Strap AF
å 7 RCiLG0007MEZZ M Degaussing Coil AN
å 8 RCiLH0095MEZZ M Deflection Yoke BB
å 9 VB63AFW32X/*S M Picture Tube (V101) CK
10 LX-TZ3013MEFD M Screw x4 AA
11 XTASD30P12000 J Screw AA
12 LX-TZ3011CEFD J Screw AA
13 VSP0080PBK98A J Speaker AP
14 XTASD40P16000 J Screw AA
15 GCABB1143MEKA M Cabinet-Rear
16 XTASD40P20000 J Screw x6 AA
17 LHLDZ0094PEZZ R Sensor Holder AC
18 LX-HZ3001PEFD R Screw AA
19 XHPSD30P06WS0 J Screw AA
20 LCHSM0056PEKZ R Chassis Frame AW
21 PSLDM0215PEFW R Shield Case (Top) AQ
22 PSLDM0202PEFW R Shield Case (Bottom) AK
23 PSLDM0205PEFW R Shield Case AF
24 LHLDP1051PEZZ R LED Holder AD
25 PSLDM0214PEFW R Shield Case AD
26 TLABG0036MEZZ M Label —
(25VT-K100)
26 TLABG0059MEZZ M Label —
(25VT-CK10)
27 QSW-F0001PEZZ R Rec Chip Switch (S7701) AG
28 LHLDW0013PEZZ R Wire Holder AB
29 LHLDZ0074PEZZ R H. V. Wire Holder AC
30 QCNW-2104PEZZ R Connecting Cord AF
31 QCNW-1940PEZZ R Connecting Cord AG
32 QCNW-1947PEZZ R Connecting Cord (S) AF
33 QCNW-1943PEZZ R Connecting Cord (YR) AF
34 QCNW-1942PEZZ R Connecting Cord AE
35 LHLDW1075PEKZ R Wire Holder AB
36 LHLDW1019PEKZ R Wire Holder AB
37 LHLDW0017PEKZ R Wire Holder (25VT-K100) AC
å 38 QACCD3042CESA J AC Cord AN
(25VT-K100)
39 LHLDW1008MEKZ M Degausing Coil Holder AB
40 LX-WZ3013MEFD M CRT Washer AA
41 LHLDW1060CEZZ J Wire Holder AB
å 42 QACCD3031CESA J AC Cord AM
(25VT-CK10)
43 QCNW-2079PEZZ R Connecting Cord AG
(25VT-CK10)
44 QCNW-2147PEZZ R Connecting Cord AE
(25VT-CK10)
45 LHLDW1070PEKZ R Holder AD
- End of CABINET AND MECHANICAL PARTS -
